Tipper Hydraulic Kit: Contents, Types and Selection
Hypo Hydraulic
A tipper hydraulic kit (tipping set) is a matched hydraulic package of pump, cylinder, valve, oil tank, PTO connection and hoses that raises the body of a tipper truck or trailer. Buying a kit instead of loose parts keeps pressure, flow and safety settings aligned.
Bodybuilders, fleets and maintenance teams searching for “hydraulic kit” or “tipping set” usually want to know which parts are mandatory and front-end or underbody. This guide answers both.
What’s in a Tipper Set / Hydraulic Kit?
Component | Role | Guide |
|---|---|---|
Front-end or underbody cylinder | Raises the body | Front-End · Telescopic |
Gear pump (most applications) | Flow and pressure | Gear Pump · Hydraulic Pump |
Tipping valve | Raise / hold / lower | Hydraulic Valve |
Oil tank | Storage and cooling | Kits & tanks category |
PTO | Power from the gearbox | What Is a PTO? |
Drive shaft | PTO–pump (if needed) | Drive Shaft |
Hoses, adapters, seals | Installation | Spare parts |
If the vehicle already has a suitable PTO, the kit can also be supplied as “pump + cylinder + valve + tank”. System logic: Hydraulic System.
Front-End Kit vs Underbody Kit
Front-end kit | Underbody kit | |
|---|---|---|
Cylinder position | Behind cab / front of body | Between chassis and body |
Typical cylinder | Multi-stage telescopic | Telescopic or scissor layout |
Strength | High tip angle, widely used | Lower centre of gravity on some trailers |
Watch | Mounting height, stages | Geometry and chassis fit |
The right type depends on body length, load (sand, rubble, rock), tip angle and chassis. Özceylanlar manufactures both front-end tipping cylinders and underbody cylinders.
Truck Hydraulic Kit vs Trailer Hydraulic Kit
- Truck hydraulic kit: Gearbox PTO + gear pump + tipping valve + cylinder + oil tank.
- Trailer hydraulic kit: Power from the tractor unit or a separate layout; hose lengths and tank position differ.
- OEM tipping set: Fixed parts list for series production, custom stroke and flange.
How to Choose a Tipper Hydraulic Kit
- Vehicle and body: truck/trailer, volume (m³), empty–laden weight
- Lift type: front-end or underbody; max angle
- Gearbox / PTO: make, ratio, rotation, torque
- Pump flow vs target tipping time
- Working pressure and relief-valve setting
- Oil-tank volume (heat margin)
- Duty profile: short-cycle construction work or occasional use
Cheap but mismatched parts come back as slow tipping, overheating, PTO wear and leaks.
Installation and Safety
- Engage the PTO with the vehicle stationary, per the manufacturer’s instructions.
- Bleed the system on first run; no suction leaks.
- Set the bypass to the correct pressure; protect the body at the upper limit with a mechanical stop.
- Keep hoses away from abrasion and heat.
- Do not work under a raised body.
Özceylanlar Tipper Hydraulic Kits
Manufacturing in Konya since 1974. We supply the critical kit parts — cylinder, gear pump, valve, PTO, drive shaft, oil tank — as a matched set.
- Front-end and underbody cylinders
- Gear pumps and tipping valves
- ~20,000 cylinders / ~25,000 pumps capacity, ~90% exported
- ISO 9001, CE, TS 11552, RINA ISO 3834-2
- OEM and spare parts
